Why We Look
We see these ten problems often. Many are simple to fix; structural, slab and sprinkler repairs can cost more.
1. Missing or Unlocked Safety Clips
A rising fork can lift an unclipped beam off its pins and drop the pallet above. Every beam end needs the right clip. A few dollars a beam.
2. Unanchored or Loose Uprights
Every footplate gets at least one wedge anchor; seismic areas and taller rack get two or more per plate to the engineer's spec. Missing, backed-out or cracked-slab anchors hold nothing. Check with a wrench.
3. Damaged Uprights Still Carrying Load
The bottom 4 feet of an aisle-side column takes the hits. A bent column, a torn footplate or a damaged brace needs a qualified assessment before the bay carries load again. Unload and isolate the bay, then repair or replace as the assessment says. Inspection checklist.
4. No Load Plaques
Every row needs a sign with beam and bay capacities, or the inspector assumes the worst. We produce them with the engineering.
5. Overloaded Beams
A beam pair is rated for an evenly spread load. Two 2,500 lb pallets on 96" beams rated 4,400 lb is an overload. A beam that sags a lot under load, or stays bent when empty, needs an assessment. It can mean overload, damage or a bad connection. Small sag does not prove a beam is safe. Compare real pallet weights with the capacity guide.
6. Beams Moved Without Re-Rating
Raising the first beam level for taller pallets lengthens the unsupported column below and cuts frame capacity, sometimes by half. Check the plaque or ask first.
7. Flue Spaces Closed Up
Pallets pushed into the flue between back-to-back rows, or overhanging the uprights, block sprinkler water from a fire low in the rack. Keep the flues your sprinkler design calls for open. Flue keepers stop pallets sliding in, and a painted line helps operators see the limit. Then check the flues are actually clear.
8. Wire Decks Missing, Upside Down or Wrong Size
Some loads need decks or pallet supports; some pallets sit safely on the beams. The rack design decides which. Decks too short, upside down or resting on one beam are not doing their job. Size decks to frame depth and beam type: wire deck styles.
9. Column Protection Only on the Drawing
End-of-aisle columns and the first upright in a row get hit most. Guards cost a fraction of the frame.
10. Forklifts the Rack Was Never Designed For
Rack laid out for a reach truck in 9 ft aisles, then run with a sit-down counterbalance, gets hit. Size the aisle to the largest truck that enters it. If the fleet changed, recheck the aisle width.
The Fix
An inspection takes a morning. We mark problems on a drawing and quote the repairs, plus the engineering letter if needed. Book an inspection or use the checklist.
